  • discoelk
    replied
    Hell yeah. The m-tech sedans are my favorite E46 form factor. The wagon is a close 2nd.

    Leave a comment:


  • Bry5on
    replied
    Originally posted by discoelk View Post
    Are you keeping it narrow body?
    You know it

    Leave a comment:


  • discoelk
    replied
    Are you keeping it narrow body?

    Leave a comment:


  • karter16
    replied
    haha that photo looking up from underneath past the muffler, through the trunk floor that isn't there and out through the rear window really tripped me out for a second 😂

    Leave a comment:


  • Bry5on
    replied
    Another afternoon of progress. Lots of little work on the trunk floor in prep and I decided I should probably test fit the muffler before permanently attaching everything.

    Good news, all the measurements checked out and it fits perfect!

    I realized in all this that the trunk floor is 12.5lbs lighter and the muffler is … 12.5lbs heavier. Classic.

    I’ll let the photos do the talking:​
    Click image for larger version

Name:	IMG_0088.jpg
Views:	128
Size:	172.3 KB
ID:	365598
    Click image for larger version

Name:	IMG_0090.jpg
Views:	132
Size:	175.8 KB
ID:	365600
    Click image for larger version

Name:	IMG_0091.jpg
Views:	129
Size:	202.0 KB
ID:	365599
    Click image for larger version

Name:	IMG_0092.jpg
Views:	131
Size:	156.7 KB
ID:	365597
    Click image for larger version

Name:	IMG_0093.jpg
Views:	128
Size:	108.4 KB
ID:	365596
    Click image for larger version

Name:	IMG_0094.jpg
Views:	129
Size:	127.7 KB
ID:	365595
    Click image for larger version

Name:	IMG_0098.jpg
Views:	140
Size:	86.5 KB
ID:	365593
    Click image for larger version

Name:	IMG_0103.jpg
Views:	129
Size:	185.7 KB
ID:	365594
    Click image for larger version

Name:	IMG_0101.jpg
Views:	132
Size:	212.4 KB
ID:	365601

    Leave a comment:


  • George Hill
    replied
    This is really interesting to me. It looks like the E46 M3s have (3)? configurations:
    • CSL - Have NO LDP or DMTL at all
    • Euro - Have LDP pre 09/01 and DMTL after
    • US - Have LDP pre 09/01 and DMTL after
    Early MS42 E46s only had the LDP and I've used Euro software with no fault suppression and didn't have heater faults. Does the Euro software show anything about heaters?

    My understanding is that the DMTL is the same thing (essentially) as LDP but with the heater added so 4 wire vs 3 wire.

    Leakage Diagnosis Pump
    Diagnostic Module for Tank Leakage

    DMTL wiring drops down through the hole with the ride height sensor:

    Click image for larger version

Name:	image.png
Views:	158
Size:	788.2 KB
ID:	365514​

    Click image for larger version

Name:	image.png
Views:	147
Size:	406.7 KB
ID:	365515​

    Click image for larger version

Name:	image.png
Views:	143
Size:	149.7 KB
ID:	365516​

    Leave a comment:


  • karter16
    replied
    Haha good call! no point in having it enabled if it's not being monitored for errors! Set the control (CTL) byte of DTC 0x0E to 0x03 :-) Have checked the disassembly and it's just this one code to change.

    Click image for larger version  Name:	Screenshot 2026-08-31 at 5.31.24 PM.png Views:	0 Size:	67.5 KB ID:	365474

    Leave a comment:


  • Bry5on
    replied
    Originally posted by karter16 View Post

    Bingo - yep that's it.

    LDPH is disabled by default in 0401 (K_LDPH_CFG == 0) The code for the module is there so technically I don't see any reason you couldn't enable it in the config. but I bet that's not the path you're thinking of taking
    Oh that’s interesting. I mean I’m game to run it if it’s better for the environment (knowing if there’s a leak I mean), but even with LDP enabled it probably still doesn’t have code for the heater portion from DMTL? Serious nuance here. Hah

    Leave a comment:


  • karter16
    replied
    Originally posted by Bry5on View Post

    George Hill just pointed out to me that euro cars may not have the evap heater and thus would be missing the thicker gauge wires. Now I’m wondering if the 0401 CSL software even turns the heater on, or if it’s just vestigial.
    Bingo - yep that's it.

    LDPH is disabled by default in 0401 (K_LDPH_CFG == 0) The code for the module is there so technically I don't see any reason you couldn't enable it in the config. but I bet that's not the path you're thinking of taking

    Leave a comment:


  • Bry5on
    replied
    Originally posted by karter16 View Post

    Let me investigate further, maybe I’m misleading you. Will have a look in more detail this evening and report back


    Sent from my iPhone using Tapatalk
    George Hill just pointed out to me that euro cars may not have the evap heater and thus would be missing the thicker gauge wires. Now I’m wondering if the 0401 CSL software even turns the heater on, or if it’s just vestigial.

    Leave a comment:


  • karter16
    replied
    Originally posted by Bry5on View Post
    So I thought I had it straight as bigjae46 says but karter16 that doesn’t look like a big enough wire bundle? That looks like the ride height sensor wires in your car to me. Most photos I’ve found look like yours with that little bundle. My touring has the ride height sensor wires there and it looks very similar.

    Do European cars have less wiring for the evap system?
    Let me investigate further, maybe I’m misleading you. Will have a look in more detail this evening and report back


    Sent from my iPhone using Tapatalk

    Leave a comment:


  • Bry5on
    replied
    So I thought I had it straight as bigjae46 says but karter16 that doesn’t look like a big enough wire bundle? That looks like the ride height sensor wires in your car to me. Most photos I’ve found look like yours with that little bundle. My touring has the ride height sensor wires there and it looks very similar.

    Do European cars have less wiring for the evap system?

    Leave a comment:


  • karter16
    replied

    I don’t have any pics of underneath unfortunately…


    Sent from my iPhone using Tapatalk

    Leave a comment:


  • bigjae46
    replied
    The hole in the bottom pic has a rubber boot with the EVAP wiring passing through it.

    If you use a hole saw, start the hole and the finish with the drill on reverse. Once the teeth start digging into the carbon it will go quick since I think Iaid up core material there. Then 120 grit sand paper to remove any frayed strands.

    Leave a comment:


  • Bry5on
    replied
    Now you've got me wanting a milkshake - I think that'll be my next move today.

    Took a few hours this morning to make the full commitment. Here we go! 16lbs removed, 3.5lbs added back in:
    Click image for larger version

Name:	IMG_0063.jpg
Views:	160
Size:	120.4 KB
ID:	365439
    Click image for larger version

Name:	IMG_0067.jpg
Views:	164
Size:	167.8 KB
ID:	365441

    Carbon panel fits pretty well, exhaust hanger fits great. This should all go together nicely.
    Click image for larger version

Name:	IMG_0070.jpg
Views:	163
Size:	178.2 KB
ID:	365440
    Click image for larger version

Name:	IMG_0066.jpg
Views:	164
Size:	137.2 KB
ID:	365437
    Click image for larger version

Name:	IMG_0074.jpg
Views:	175
Size:	109.5 KB
ID:	365435

    And I'm reminded of why welding subframe reinforcement plates is a bad idea (this area had road dust in it, as it's technically exposed to the environment. I will be painting this part up to at least keep that section of corrosion at bay.
    Click image for larger version

Name:	IMG_0068.jpg
Views:	168
Size:	121.8 KB
ID:	365438
    Click image for larger version

Name:	IMG_0069.jpg
Views:	167
Size:	121.3 KB
ID:	365436

    Anyone know how the wiring for the M3 evap system is run through/out of the cabin? It looks like it's reasonably different than the non-m and I'm going to at least need to reroute that harness. Could use some pointers as it's hard to find photos of that system.
