It bolts in with 5 fasteners, lifts out upward and I'm ordering cam locks (like a bike seat post) for quick removal. If I do this right, it's a no-tool install/removal for hatch access on the fly.

That is epic! Absolutely best of both worlds!


Sent from my iPhone using Tapatalk

[Bry5on]

Excited to see/hear how this goes. Are you planning for this to be removable for when you need the load-thru access? (Looks like you might be but not sure how complex install/uninstall is expected to be?)


Sent from my iPhone using Tapatalk

It bolts in with 5 fasteners, lifts out upward and I'm ordering cam locks (like a bike seat post) for quick removal. If I do this right, it's a no-tool install/removal for hatch access on the fly.

[karter16]

Alright, a few tweaks and I decided to pick up the center isofix mount as well. Parts are ordered, this should be a nice change if the Slon wall in the M3 is any indication.

Excited to see/hear how this goes. Are you planning for this to be removable for when you need the load-thru access? (Looks like you might be but not sure how complex install/uninstall is expected to be?)


Sent from my iPhone using Tapatalk

[Bry5on]

Alright, a few tweaks and I decided to pick up the center isofix mount as well. Parts are ordered, this should be a nice change if the Slon wall in the M3 is any indication.

[Bry5on]

No no no. You used CAD-- cardboard aided design.

Just installed this bracket. Thanks!

I should probably do this next project with said CAD..

So instead of working on any of the projects I've already got in flight, I decided to jump into CAD land to work on a simpler one. Making the touring chassis even more rigid! Still need to design the clevis mounts but this will bolt in using factory mounting points for the seat latches and the gear lashing hooks. Both things that should be able to take some decent loads.

I'm also not set on sheet metal because it would need something to stiffen it up, but it's a start.

[Obioban]

After an iteration of carboard engineering, to borrow a term from Heinz, I designed a three bracket system, laser cut it and bolted it to the transmission.

No no no. You used CAD-- cardboard aided design.

Just installed this bracket. Thanks!

[Bry5on]

Okay, now we're talking. This should work with milled down e39 bushings inserted into the knuckles. The nice thing about that approach is that I don't need to cut or ream a taper myself, just turn or mill the factory e39 bushings.

What remains to be seen is whether the rubber boot can compress an extra millimeter more than stock and, if there is enough thread engagement, if I can increase the depth of the press-in bushing to drop the load on the bottom edge of the knuckle a little bit. As you can see, I've got a safety factor of 2 everywhere, but would really like something around 3 everywhere

[Bry5on]

Had a revelation today. I've been struggling to get the stress analysis to close ever since I started modeling the tie rod tapers as 4340 steel mating parts. I remembered that the e39 used a taper like the e46 does, and also had aluminum uprights, so I couldn't figure out why my analysis wasn't closing. Well, it's because the e39 has a steel insert where the loads would otherwise fail the aluminum part. Nice, that'll do it.


So looks like I need to make a trip to the junk yard this weekend to rip some of these bushings out of an e39, take some dimensions, then see if I should use the e39 bushings or design mating parts for the e46. I fear that there is not enough thread engagement on the e46 M3 control arm to use the e39 bushings as-is, so they'll probably need to make a trip to the lathe.

e39 bushing being pressed out (instead of the ball joint) to visualize it:


and the bushing after it came out:

[Bry5on]

Couldn't help it, dropped the control arms and tie rods 30mm and added a second strut support 80mm higher, then tipped the strut in 4 degrees for ~20mm extra inner wheel and tire clearance. Here's the unrestricted by manufacturing constraints result:

[Bry5on]

I thought you were doing a custom control arm as well? If that was the case, you should convert to that design anyway.

Yeah I was kinda hoping to make each part a bolt-in but you might be right, just go full send. Let's see where the math takes us first.

[YoitsTmac]

I thought you were doing a custom control arm as well? If that was the case, you should convert to that design anyway.

[Bry5on]

Also while we're on the subject of setting things right for the record, my 1:10 tapered reamer showed up. After fitting it into the stock e46 M3 tie rod and control arm balljoint locations, I can confirm without a doubt that the BMW taper is a 1:10 Diameter:Length, rather than a 1:8 or a 7 degree, cited elsewhere on the internet. This means that for every ten millimeters of length in the taper, the diameter grows 1mm. Yes, diameter, not radius. Always measure yourself folks!!

Also, based on the torques BMW is calling out for the control arm and tie rod M14 and M12 nuts, respectively, this is likely around a steel equivalent to a Grade 5.8 fastener. Plugging these numbers into the simulation yields the following results - the tie rod and knuckle will fail about the same time:




All this had me thinking some more. Once I get a control arm here to measure, I can press out the outer ball joint, and if it happens to be a common diameter (perhaps the same as the rears) then I can press in a bushing designed for double-shear. And instead of doing the factory taper joint, I can design this thing for a much stronger and stiffer double shear joint at the control arm. Porsche did this for the 991.2+ generation GT 911 and I always thought this was a really clever way to stiffen the knuckle up and provide better wheel control, see below:


And last, a fellow member has asked me to consider making a knuckle that is designed to:
1) Correct the geometry of lowered track cars (this would have the effect of making more stable geometry and also increase front roll stiffness, so you can soften the front sway bar and still get good roll control)
2) Move the strut mount more inboard so you can fit more front tire by going inward

I've been thinking more about this, specifically #2, and how I think we might be able to mitigate the downside of the increased bending moment on the strut tube from relocating it inboard. If we play our cards right, we can achieve another 20mm or so of inner tire clearance AND stiffen the strut up to make it respond even better to mid-corner damping and displacement changes. And also last longer, because it will be bending less. So this is intriguing and I may pursue it. Again, see below from Porsche for inspiration, noting the two clamps on the strut, one of which is placed very high up:

[Bry5on]

Alright, so a couple people were skeptical that the e60 hubs would be compatible with the e46 DSC, enough so that it was starting to make me nervous. So let's address that in two ways:

First, let's break out the oscilloscope and check the output signals directly. These sensors are pretty clever, they are *active* and not passive like MK20. They output a square wave with a very short pull down from 12V to ~6V when they detect a trigger on the hub (this is very different from the e9x and e60 M5 still).


Here's what the e46/e6x non-M looks like on the active 2-wire system when spinning.


Ok, so we're looking good so far, let's make 100% sure we're right here by plugging the e60 sensor into the e46(it has the exact same keying on the connector) and firing up INPA to read the individual wheel speeds.



And would you look at that, it reads the sensor just perfectly

[Bry5on]

Hi Bryson... as for load cases I can think off...

* Pot hole, tough to estimate. I can ask around here to see if there is any directional input, like shock g's and damper speed.
* hitting a curb, although the week link here is the tie rod.

since we have more unknowns than not, one idea is to scan the OE design, and run the same modes, then you can have two data points you can use to compare under the same conditions.

Yeah, good idea. I was waiting for you to pop in here. thank you.

I’ve got the scan of the OE parts, just need to close the holes and make it a solid body.

I’ve also done a quick model of the tapered joints on the control arm and tie rod and placed the appropriate loads that put the tapers in bending. At first blush it looks like the control arm taper will fail before the knuckle by a small amount. I’ll need to disassemble a control arm to get good dimensions of the taper to make sure, I just estimated length of the taper based on an old iPhone scan.

[maupineda]

Hi Bryson... as for load cases I can think off...

* Pot hole, tough to estimate. I can ask around here to see if there is any directional input, like shock g's and damper speed.
* hitting a curb, although the week link here is the tie rod.

since we have more unknowns than not, one idea is to scan the OE design, and run the same modes, then you can have two data points you can use to compare under the same conditions.
