    The spacers worked great as a quick, easy and cheap fix for the lower front ride height that I didn't want, but I realize they don't make sense for everyone.

    The exhaust clamps are 100% worth it. Super cheap and took like 10 min to install.
    2002 Topasblau M3 - Coupe - 6MT - Karbonius CSL Airbox - MSS54HP Conversion - Kassel MAP - SSV1 - HJS - PCS Tune - Beisan - MK60 Swap - ZCP Rack - Nogaros - AutoSolutions - 996 Brembos - Slon - CMP - VinceBar - Koni - Eibach - BlueBus - Journal

    2012 Alpinweiss 128i - Coupe - 6AT - Slicktop - Manual Seats - Daily - Journal

    Comment


      When I found both lower wishbone to subframe bolts loose, I torqued them back up, but was only able to get a torque wrench in on the passenger side. Driver's side I did using the double wrench thing. Wasn't too confident that it was torqued properly, so I bought a stubby socket. Surprisingly, it still wouldn't fit, so I had to cut the thing down:

      Click image for larger version

Name:	20230321_190256.jpg
Views:	527
Size:	201.2 KB
ID:	210848
      Click image for larger version

Name:	20230321_191804.jpg
Views:	515
Size:	250.4 KB
ID:	210849
      Click image for larger version

Name:	20230321_191816.jpg
Views:	511
Size:	209.2 KB
ID:	210850

      Barely any socket left after that, but it worked! Still need to fix the subframe with the mending plates, but that will come later.

      After that, I was pulling out of a parking spot and heard/felt a crunch when turning the steering wheel. It only did it once, so I figured it wasn't an issue. However, on the way back home, I noticed that none of my steering wheel controls were working. So I took things apart and found this:

      Click image for larger version

Name:	20230318_144811.jpg
Views:	508
Size:	101.5 KB
ID:	210851

      Somehow one of the clock spring ribbon connectors failed. I didn't get an airbag light, but nothing else on the steering wheel worked. I guess the signal wires for the airbag are on the ribbon that didn't fail.

      Was halfway through soldering the thing back on when I decided that I didn't want to risk driving around with a non-functional airbag:

      Click image for larger version

Name:	20230318_150458.jpg
Views:	514
Size:	176.7 KB
ID:	210852

      Fine, I'll give BMW the stupid $200 that they want for a new one.

      Also, the thing was surprisingly annoying to take apart. Here's how I did it for documentation purposes:

      Click image for larger version

Name:	20230318_144537.jpg
Views:	512
Size:	98.3 KB
ID:	210853
      Click image for larger version

Name:	20230318_144756.jpg
Views:	516
Size:	120.2 KB
ID:	210854
      2002 Topasblau M3 - Coupe - 6MT - Karbonius CSL Airbox - MSS54HP Conversion - Kassel MAP - SSV1 - HJS - PCS Tune - Beisan - MK60 Swap - ZCP Rack - Nogaros - AutoSolutions - 996 Brembos - Slon - CMP - VinceBar - Koni - Eibach - BlueBus - Journal

      2012 Alpinweiss 128i - Coupe - 6AT - Slicktop - Manual Seats - Daily - Journal

      Comment


        Was reading through the BlueBus thread and saw that some people were adding ground loop isolators to theirs. My throttle actuator seems to add a fair amount of interference, so I bought the necessary connectors + the isolator and made one real quick.

        The isolator came with a 3.5mm male to male wire, so I cut that in half and crimped terminals to the cut ends. Ted mentioned that the car side connector needs both ground pins populated, so made sure to do that:

        Click image for larger version

Name:	20230319_193437.jpg
Views:	539
Size:	83.6 KB
ID:	210858
        Click image for larger version

Name:	20230319_204042.jpg
Views:	518
Size:	98.9 KB
ID:	210859
        Click image for larger version

Name:	20230319_213907.jpg
Views:	513
Size:	101.6 KB
ID:	210860
        Click image for larger version

Name:	20230320_164250.jpg
Views:	503
Size:	86.4 KB
ID:	210861
        Click image for larger version

Name:	20230320_164306.jpg
Views:	513
Size:	92.8 KB
ID:	210862

        Fortunately all of Ted's stuff is open source, so no need to go probing with a multimeter to find out what is what. Instead, I just pulled up the schematics and based everything on that: https://cadlab.io/project/1479/maste...ZUJ1cy5zY2g%3D

        Difference is huge. I was getting both a low frequency hum and a higher frequency noise (from the throttle actuator) as interference before. Pretty much dead silent now.

        Here's the before. Creaking noise is me actuating the throttles to get the interference to come through:



        And after:



        I can hear some very slight high frequency pops with the isolator in, but I don't know for sure that those weren't there before. I have a feeling that the radio volume was set a lot higher during the test with the isolator and that's why those pops were audible. Either way, much happier with it now.
        2002 Topasblau M3 - Coupe - 6MT - Karbonius CSL Airbox - MSS54HP Conversion - Kassel MAP - SSV1 - HJS - PCS Tune - Beisan - MK60 Swap - ZCP Rack - Nogaros - AutoSolutions - 996 Brembos - Slon - CMP - VinceBar - Koni - Eibach - BlueBus - Journal

        2012 Alpinweiss 128i - Coupe - 6AT - Slicktop - Manual Seats - Daily - Journal

        Comment


          Today I left my key in the pocket of my jeans and put them in the washing machine. Key still works lol
          2002 Topasblau M3 - Coupe - 6MT - Karbonius CSL Airbox - MSS54HP Conversion - Kassel MAP - SSV1 - HJS - PCS Tune - Beisan - MK60 Swap - ZCP Rack - Nogaros - AutoSolutions - 996 Brembos - Slon - CMP - VinceBar - Koni - Eibach - BlueBus - Journal

          2012 Alpinweiss 128i - Coupe - 6AT - Slicktop - Manual Seats - Daily - Journal

          Comment


            Never mind it died
            Oh well, back to using the worse looking key
            2002 Topasblau M3 - Coupe - 6MT - Karbonius CSL Airbox - MSS54HP Conversion - Kassel MAP - SSV1 - HJS - PCS Tune - Beisan - MK60 Swap - ZCP Rack - Nogaros - AutoSolutions - 996 Brembos - Slon - CMP - VinceBar - Koni - Eibach - BlueBus - Journal

            2012 Alpinweiss 128i - Coupe - 6AT - Slicktop - Manual Seats - Daily - Journal

            Comment


              Track day tomorrow, so got the car ready for that.

              Clock spring replaced with a new one:

              Click image for larger version

Name:	20230330_185026.jpg
Views:	541
Size:	100.2 KB
ID:	212706

              Then got an alignment:

              Click image for larger version

Name:	20230406_110850.jpg
Views:	487
Size:	98.5 KB
ID:	212707

              Rear camber is maxed out. I really need some camber arms, but I'm dreading the install. I did order some E36 diff bushings to replace the poly ones I have, so maybe that'll finally get me to do it.

              I also bought a rear dashcam for the car. I decided to tap into the existing parking mode power module and run a long USB cable to the rear. Soldered some stuff and ended up with two output wires from the module:

              Click image for larger version

Name:	20230331_223838.jpg
Views:	478
Size:	72.1 KB
ID:	212708
              Click image for larger version

Name:	20230331_234632.jpg
Views:	479
Size:	70.7 KB
ID:	212709

              Also added a connector for the long cable for easier servicing:

              Click image for larger version

Name:	20230401_001800.jpg
Views:	479
Size:	86.5 KB
ID:	212710

              Now onto routing the cable. Easy choice would have been to route it along the seam between the headliner and the door, but I really didn't want to have it interfere with the side airbags, so I did it a bit differently.

              Here's the output out front:

              Click image for larger version

Name:	20230405_091836.jpg
Views:	479
Size:	111.4 KB
ID:	212711

              Connected the long cable and routed it back towards the sunroof:

              Click image for larger version

Name:	20230405_091954.jpg
Views:	491
Size:	134.0 KB
ID:	212712

              I then routed the wire along the perimeter of the sunroof, this definitely keeps it far enough from the airbag:

              Click image for larger version

Name:	20230405_092122.jpg
Views:	490
Size:	141.1 KB
ID:	212713

              Pulled it out through the alarm ultrasonic sensor hole (just as a middle stop cause feeding it all the way to the rear was not easy):

              Click image for larger version

Name:	20230405_092429.jpg
Views:	482
Size:	90.6 KB
ID:	212714

              Fed it through to the third brake light area:

              Click image for larger version

Name:	20230405_094155.jpg
Views:	494
Size:	216.9 KB
ID:	212715

              And out the passenger C pillar:

              Click image for larger version

Name:	20230405_094205.jpg
Views:	495
Size:	196.4 KB
ID:	212716

              Still had some wire left, so I zip tied that out of the way:

              Click image for larger version

Name:	20230405_101953.jpg
Views:	493
Size:	206.5 KB
ID:	212717

              Trim back on and done:

              Click image for larger version

Name:	20230405_114852.jpg
Views:	492
Size:	199.6 KB
ID:	212718

              I did rip some of the fabric off of the pillar trim when reinstalling, so I reglued that real quick, no big deal. Pretty happy with the end result and install was a lot less painful than I expected.
              2002 Topasblau M3 - Coupe - 6MT - Karbonius CSL Airbox - MSS54HP Conversion - Kassel MAP - SSV1 - HJS - PCS Tune - Beisan - MK60 Swap - ZCP Rack - Nogaros - AutoSolutions - 996 Brembos - Slon - CMP - VinceBar - Koni - Eibach - BlueBus - Journal

              2012 Alpinweiss 128i - Coupe - 6AT - Slicktop - Manual Seats - Daily - Journal

              Comment


                You should’ve gone with CSL rear toe specs! Also, you want my ground control spherical lower control arms?
                ‘02 332iT / 6 | ‘70 Jaguar XJ6 electric conversion

                Comment


                  Originally posted by Bry5on View Post
                  You should’ve gone with CSL rear toe specs! Also, you want my ground control spherical lower control arms?
                  I thought about it, but didn't want to mess too much with toe before a track day. I've learned that toe really impacts how much I enjoy driving the car and decided I'd rather stick with something that I know is fine, rather than spend the whole track day annoyed because I didn't end up liking the change. Will probably mess around with it when I do the camber arms though.

                  Did you end up getting the turner ones instead?
                  2002 Topasblau M3 - Coupe - 6MT - Karbonius CSL Airbox - MSS54HP Conversion - Kassel MAP - SSV1 - HJS - PCS Tune - Beisan - MK60 Swap - ZCP Rack - Nogaros - AutoSolutions - 996 Brembos - Slon - CMP - VinceBar - Koni - Eibach - BlueBus - Journal

                  2012 Alpinweiss 128i - Coupe - 6AT - Slicktop - Manual Seats - Daily - Journal

                  Comment


                    I got ECS ones as Turner was out of stock for a while. the adjusters are in the center which is not as good as at the wheel, but better than at the subframe/above the exhaust.

                    Give the wagon a shot, you should be able to feel the difference in toe on initial turn in, but it might be tough to differentiate from the rebuilt rack at this point. Really good change IMO
                    ‘02 332iT / 6 | ‘70 Jaguar XJ6 electric conversion

                    Comment


                      Originally posted by Bry5on View Post
                      I got ECS ones as Turner was out of stock for a while. the adjusters are in the center which is not as good as at the wheel, but better than at the subframe/above the exhaust.

                      Give the wagon a shot, you should be able to feel the difference in toe on initial turn in, but it might be tough to differentiate from the rebuilt rack at this point. Really good change IMO
                      I'll take you up on that offer, also want to feel that new rack. Now that I have the MK60 in the car, I'll probably look into swapping racks.
                      2002 Topasblau M3 - Coupe - 6MT - Karbonius CSL Airbox - MSS54HP Conversion - Kassel MAP - SSV1 - HJS - PCS Tune - Beisan - MK60 Swap - ZCP Rack - Nogaros - AutoSolutions - 996 Brembos - Slon - CMP - VinceBar - Koni - Eibach - BlueBus - Journal

                      2012 Alpinweiss 128i - Coupe - 6AT - Slicktop - Manual Seats - Daily - Journal

                      Comment


                        I'd like to do this. What connectors did you buy?

                        Comment


                          Originally posted by heinzboehmer View Post
                          Today I left my key in the pocket of my jeans and put them in the washing machine. Key still works lol

                          I have done that once with my keys for the ZHP and it still worked.

                          Comment


                            Originally posted by Obergoose View Post
                            I'd like to do this. What connectors did you buy?
                            For which project? I've bought a ridiculous amount of connectors lately

                            Originally posted by BADCLOWN View Post
                            I have done that once with my keys for the ZHP and it still worked.
                            I wish mine still did. Oh well
                            Last edited by heinzboehmer; 04-23-2023, 10:02 PM.
                            2002 Topasblau M3 - Coupe - 6MT - Karbonius CSL Airbox - MSS54HP Conversion - Kassel MAP - SSV1 - HJS - PCS Tune - Beisan - MK60 Swap - ZCP Rack - Nogaros - AutoSolutions - 996 Brembos - Slon - CMP - VinceBar - Koni - Eibach - BlueBus - Journal

                            2012 Alpinweiss 128i - Coupe - 6AT - Slicktop - Manual Seats - Daily - Journal

                            Comment


                              Track day was some time ago, but it went great. Felt awesome to be back at Thunderhill on 200 tw tires.

                              First two sessions were wet (first time ever on a track in the wet!) and the RE71R had absolutely zero grip. To the point where it wasn't exactly fun to drive out. Wish I had had the 4Ss on. Managed to stay on track throughout both sessions though.

                              Next track day is in two weeks and I'm running low on both brake pads and tires. Have two sets of mostly worn track pads that I want to eat through so that I am finally motivated to get the 996 calipers on the car. Track tires will likely die that day, so need to bring my street tires to get back home. Will be interesting fitting all that into the car. This is what the trunk looks like now:

                              Click image for larger version

Name:	20230503_184740.jpg
Views:	371
Size:	146.6 KB
ID:	216566

                              Will need to figure out how to get the street tires into the back seat with the nogaros installed. Bought a set of tire totes in anticipation of this, but probably still not going to be very fun.
                              2002 Topasblau M3 - Coupe - 6MT - Karbonius CSL Airbox - MSS54HP Conversion - Kassel MAP - SSV1 - HJS - PCS Tune - Beisan - MK60 Swap - ZCP Rack - Nogaros - AutoSolutions - 996 Brembos - Slon - CMP - VinceBar - Koni - Eibach - BlueBus - Journal

                              2012 Alpinweiss 128i - Coupe - 6AT - Slicktop - Manual Seats - Daily - Journal

                              Comment


                                Man that inflator is garbage and I'm a makita guy.
